Bone Gouges — Pattern and Clinical Use
Where an osteotome makes a flat cut, a gouge removes a curved channel. The semicircular blade cuts a trough through cancellous bone, which is how bone graft is harvested from the iliac crest and how curved surfaces are shaped. The curvature of the blade determines the profile of the trough, so gouges are supplied in a range of radii as well as widths.
The cutting edge runs around a curve, which makes it harder to sharpen and to keep uniform than a straight blade — edge consistency around the full arc is the manufacturing challenge on this pattern.
Bone Gouges Variants and Specifications
Standard bone gouge patterns.
| Variant | Specification / use |
|---|---|
| Narrow curve, 6–10 mm | Fine trough and channel |
| Medium curve, 13–20 mm | General graft harvest |
| Wide curve, 25–32 mm | Broad cancellous harvest |
| Deep radius | Narrow deep trough |
| Shallow radius | Broad shallow scoop |
| Impact-rated handle | Withstands mallet blows |
Material, Finish and Quality Control
We forge bone gouges from AISI 420 martensitic stainless. Edge sharpness is verified around the full arc of the curve, which is harder to hold uniform than on a straight blade. Each batch passes Rockwell hardness testing, dimensional checks on edge consistency around the arc, and visual inspection under our ISO 13485 system before passivation and final finishing. Mirror and satin finishes are both available — satin is usually specified where glare under operating lights is a concern.
Who Sources Bone Gouges From Surgical Star
Bone gouges sell to orthopedic and spinal distributors as part of bone graft harvesting sets, usually alongside osteotomes and mallets.
OEM, Certification and Ordering
Every bone gouges can be produced as a private-label line: your logo laser-marked on the shank, your catalog numbers, and your own printed packaging, manufactured from your drawings or a reference sample. Production runs inside a documented ISO 13485 quality system, with CE marking under EU MDR 2017/745 and US FDA establishment registration behind it. Your shipment carries a certificate of conformity plus the ASTM F899 material certificate for the grade actually used.
Minimums stay deliberately low so a new brand can launch without a heavy first order, and pricing is quoted direct from the factory on volume tiers. Bulk production usually takes four to six weeks from sample approval, shipped DDP with export paperwork and HS codes handled. See how OEM & private label works →
Related Orthopedic Instruments
Frequently Asked Questions
What is a gouge used for that an osteotome is not?
Removing a curved trough of bone rather than making a flat cut — principally harvesting cancellous graft and shaping curved surfaces.
What determines the trough profile?
The radius of the blade curve. Gouges are supplied in a range of radii as well as widths so the trough matches what is needed.
Why is edge consistency harder on a gouge?
The cutting edge runs around a curve rather than a straight line, so holding uniform sharpness across the whole arc is more demanding.
Can you manufacture these under our own brand?
Yes — full OEM and private label. We laser-mark your logo and catalog numbers, pack in your branded boxes, and work from your drawings, tech pack or a reference sample, with a pre-production sample approved before any bulk run.
Send your pattern list, drawing or a reference sample and we’ll quote MOQ, pricing and lead time — standard catalog or fully private-label.
