Hohmann Retractors — Pattern and Clinical Use
The Hohmann works as a lever rather than a hook. Its pointed tip is placed over the far side of the bone to anchor, then the handle is levered so the broad blade sweeps soft tissue clear of the operative field — which is exactly how the femur and acetabulum are exposed in hip arthroplasty and how bone is exposed in fracture surgery.
Blade width and tip length are the ordering variables, and both matter clinically: too short a tip does not anchor and the retractor slips, while blade width determines how much tissue is held. Narrow-tipped patterns are used where the anchor point is confined.
Hohmann Retractors Variants and Specifications
Standard Hohmann patterns.
| Variant | Specification / use |
|---|---|
| Narrow blade, 8–15 mm | Confined exposure |
| Standard blade, 18–24 mm | General bone exposure |
| Wide blade, 43–60 mm | Hip arthroplasty exposure |
| Long tip | Deeper anchorage behind bone |
| Short tip | Shallow or confined anchor point |
| Curved / angled blade | Follows bone contour |
Material, Finish and Quality Control
We forge Hohmann retractors from 316L austenitic stainless. Tip strength is load-tested and blade edges radiused, since the instrument levers substantial force through a single anchor point. Each batch passes Rockwell hardness testing, dimensional checks on tip strength under levering load, and visual inspection under our ISO 13485 system before passivation and final finishing. Mirror and satin finishes are both available — satin is usually specified where glare under operating lights is a concern.
Who Sources Hohmann Retractors From Surgical Star
Hohmann retractors sell in quantity to orthopedic and arthroplasty distributors, and are ordered across a wide range of blade widths since several are used simultaneously in a hip exposure.
OEM, Certification and Ordering
Every Hohmann retractors can be produced as a private-label line: your logo laser-marked on the handle, your catalog numbers, and your own printed packaging, manufactured from your drawings or a reference sample. Our quality file is ISO 13485, our EU route is CE marking under MDR 2017/745, and our facility holds US FDA establishment registration. Conformity and ASTM F899 material certificates are issued against each order.
You order direct from the factory with no trading-house margin, on volume-tiered pricing and a minimum matched to your pattern and finish. Once your branded sample is signed off, expect roughly four to six weeks to bulk delivery, worldwide DDP. See how OEM & private label works →
Related Orthopedic Instruments
Frequently Asked Questions
How does a Hohmann retractor work?
The pointed tip anchors over the far side of the bone, then the handle is levered so the broad blade sweeps soft tissue clear of the field.
What blade widths are needed?
A wide range, since several are used simultaneously in an exposure. Narrow blades for confined access, wide blades for hip arthroplasty.
Why does tip length matter?
Too short a tip does not anchor behind the bone and the retractor slips out under levering load.
Can you manufacture these under our own brand?
Yes — full OEM and private label. We laser-mark your logo and catalog numbers, pack in your branded boxes, and work from your drawings, tech pack or a reference sample, with a pre-production sample approved before any bulk run.
Send your pattern list, drawing or a reference sample and we’ll quote MOQ, pricing and lead time — standard catalog or fully private-label.
